Product Description
Sleek and streamlined, this adaptable detector is fully submersible and can target all types and ground conditions.
Sleek and streamlined, this adaptable detector is fully submersible and can target all types and ground conditions. Powered by Minelab’s Multi-IQ Simultaneous Multi-Frequency Technology, it offers simple, smart detection performance.
|
|
|
|
---|---|---|---|
MULTI-IQ TECHNOLOGY:Minelab’s revolutionary technology combines the power of multiple detectors into one, allowing you to effectively search all metals, all soils, all the time. |
FULLY WATERPROOFDon’t stop at the beach or the bank, this fully submersible model allows you to detect under the surface of oceans, rivers, streams and lakes up to 3m (10 ft). |
3 DETECT MODESEasily select from Park, Field or Beach modes to focus on target types or ground conditions. |
ACCURATE TARGET IDIdentify your targets quickly and confidently to efficiently sort between trash and treasure. |


Technical Specifications
Detect Modes | Park | Beach | Field |
Custom Search Profiles | 6 (2 per Detect Mode) |
User Profile Button | No |
Operating Frequencies (kHz) | Multi, 5, 10, 15 |
Noise Cancel | Auto |
Ground Balance | Auto | Manual |
Sensitivity | 1-25 |
Target Volume | 0-25 |
Threshold Level | 0-25 |
Target Identification | 50 segment notch discrimination | Ferrous: -9 – 0 | Non-ferrous: 1 – 40 |
Threshold Pitch | Fixed |
Target Tones | 1, 2, 5, 50 |
Tone Break | Ferrous |
Tone Pitch | Ferrous |
Tone Volume | Ferrous |
Depth Indicator | 5 Levels |
![]() |
![]() |
![]() |
![]() |
|
---|---|---|---|---|
Minelab Equinox 600 Metal Detector with 11″ coil | Minelab Equinox 600 Metal Detector with 15″ coil | Minelab Equinox 800 Metal Detector with 11″ coil | Minelab Equinox 800 Metal Detector with 15″ coil | |
Simultaneous multi Frequency | Multi-IQ (5-40kHz) | Multi-IQ (5-40kHz) | Multi-IQ (5-40kHz) | Multi-IQ (5-40kHz) |
Audio | Internal speaker, 3.5mm headphones. (Acc – Bluetooth & WM08 WIFI, w/proof headphones) | Internal speaker, 3.5mm headphones. (Acc – Bluetooth & WM08 WIFI, w/proof headphones) | Internal speaker, Bluetooth headphones, WM08 WIFI module. (Acc – w/proof headphones available) | Internal speaker, Bluetooth headphones, WM08 WIFI module. (Acc – w/proof headphones available) |
Discrimination | 50 Segment discrimination pattern | 50 Segment discrimination pattern | 50 Segment discrimination pattern | 50 Segment discrimination pattern |
Sensitivity levels | 25 manual levels | 25 manual levels | 25 manual levels | 25 manual levels |
Weight | 1.34kg (including battery) | 1.34kg (including battery) | 1.34kg (including battery) | 1.34kg (including battery) |
Screen | Monochrome LCD with white Backlight | Monochrome LCD with white Backlight | Monochrome LCD with white Backlight | Monochrome LCD with white Backlight |
Water Proof | Yes 3m (10ft) | Yes 3m (10ft) | Yes 3m (10ft) | Yes 3m (10ft) |
Battery type | In-built Li-Ion | In-built Li-Ion | In-built Li-Ion | In-built Li-Ion |
Gold Prospecting | No | No | Yes | Yes |
Coil Size | 11 in | 15 in | 11 in | 15 in |
